Performance

Working Height 18.0 m
Platform Height 16.0 m
Horizontal Outreach 10.00 m
Working Outreach ** 10.65 m
Up and Over Height 7.30 m
Swing Non-Continuous 355°
Platform Capacity - Unrestricted 250 kg
Platform Rotator (Hydraulic) 180°
Jib – Overall Length 1.24 m
Jib - Range of articulation 145° (+76°/ -69°)
Machine weight * 7,760 kg
Maximum Ground Bearing Pressure *** 6.6 kg/cm2
Occupied floor area 7.5 m2
Drive Speed 5 km/h
Gradeability- 2WD 30%
Turning Radius – Inside 2.06 m
Turning Radius – Outside 4.78 m
