Performance

Working Height 15.72 m
Platform Height 13.72 m
Horizontal Outreach 7.62 m
Working Outreach ** 8.27 m
Up and Over Height 7.30 m
Swing Non-Continuous 355°
Platform Capacity - Unrestricted 250 kg
Platform Rotator (Hydraulic) 180°
Jib – Overall Length 1.24 m
Jib - Range of articulation 145° (+76°/ -69°)
Machine weight * 6,270 kg
Maximum Ground Bearing Pressure *** 4.0 kg/cm2
Occupied floor area 7.5 m2
Drive Speed 4.8 km/h
Gradeability 30%
Turning Radius – Inside 2.06 m
